TIRE SIZE | PLY RATING | STANDARD RIM | （mm) INFLATED SIZE OF NEW TIRE | SINGLE TIRE LOAD （kg) | CORRESPONDING AIR PRESSURE | DEEP （mm) | |
OVERALL DIAMETER | SECTION WIDTH | LOAD | PRESSURE (Kpa) | ||||
| 11-32 | 10 | W10 | 1465 | 305 | 1080 | 160 | 72 |
| 12.4-24 | 10 | W11 | 1245 | 315 | 1080 | 230 | 72 |
| 12.4-28 | 10 | W11 | 1315 | 315 | 1785 | 220 | 72 |
| 14.9-24 | 10 | W12 | 1410 | 378 | 1760 | 180 | 72 |
| 14.9-26 | 10 | W13 | 1419 | 378 | 2040 | 230 | 72 |
| 14.9-28 | 10 | W13 | 1510 | 378 | 1880 | 230 | 72 |
| 16.9-28 | 12 | W15L | 1530 | 430 | 2200 | 200 | 80 |
| 16.9-30 | 12 | W15L | 1585 | 430 | 2455 | 200 | 80 |
| 16.9-34 | 12 | W15L | 1680 | 430 | 3385 | 220 | 80 |
| 18.4-38 | 12 | W16L | 1855 | 467 | 3575 | 230 | 88 |
| 18.4-42 | 12 | W16 | 1430 | 467 | 3700 | 210 | 88 |
| 20.8-38 | 12 | W18L | 1887 | 528 | 4000 | 200 | 95 |
| 13.6-24 | 10 | W12 | 1270 | 345 | 2165 | 240 | 85 |
| 13.6-38 | 10 | W12 | 1710 | 345 | 2780 | 250 | 80 |
